Product Specifications |
| Product model number - DDHBC08NEB |
| Max. speed - 20km/h (Max speed for each mode: Pedestrian mode: 5km/h; D: 15km/h; S: 20km/h) |
| General range - 20km |
| Max. climbing angle - 10% |
| Braking - E-ABS and disc brake |
| Rated power - 250W |
| Max. power - 500W |
| Tires - 8.5" front and rear pneumatic tires |
| Controller under voltage protection - 29V ± 0.5V |
| Controller current limit - 17A±0.5A |
| Motor type - Brushless low speed DC motor |
| Max. load - 100kg |
| Rider height - 120cm-200cm |
| Rider age - 16-50 |
| Working temperature - -10°C to 40°C |
| Storage temperature - -20°C to 45°C |
| IP-rating - IP54 |
| Charging time - 3.5 hours |
| AC Power Cable |
| Plug type - 2 straight prong |
| Tail type - 8-shape |
| AC wire - H05VVH2-F |
| AC cable length - 2.0m |
| Adapter Specifications |
| Input voltage - 100-240VAC 50/60Hz |
| Input current - 2A MAX |
| Output voltage - 42VDC |
| Output current - 1.7A |
| Output power - 71W |
| DC cable length - 2m |
| DC cable port type - Custom Φ8.0*1.6mm |
| Battery Specifications |
| Battery type - Lithium-ion battery |
| Battery model - NE1002-H |
| Maximum charging voltage - 42VDC |
| Rated voltage - 36VDC |
| Rated capacity - 5100mAh /183Wh |
| Charging temperature range - 0°C — 40°C |
| Discharge temperature range - -20°C — 50°C |
| Storage time - Approx. 13 months |
| Battery weight - 1.1kg |
| Cyclical lifetime - 500 charging cycles with power maintained above 70% |
| Package Contents |
| Mi Electric Scooter Essential |
| Power adapter |
| Hexagon wrench |
| Extended nozzle adapter |
| Screw |
| User manual |
| Important information |
| Specifications |
